Item | RS735-384 | RS750-384 | RS735-640 | RS750-640 |
Sensor | Type | Uncooled Vox FPA Micro bolometer |
Pixel Array | 384×288 | 384×288 | 640×512 | 640×512 |
Pixel Pitch | 12μm |
NETD | ≤35mk(25 °C, F#=1.0) |
Image | Focal Length | 35mm | 50mm | 35mm | 50mm |
FOV(±5%) | 7.5°*5.7° | 5.3°*4.0° | 12.6°*10.1° | 8.8°*7.0° |
Min Focus | 2m | 5m | 2m | 5m |
Lens Aperture | F1.0 | F1.0 | F1.0 | F1.0 |
Frame Rate | 50HZ |
Focus method | Manual |
Display | Display | 0.49 inch Color OLED 1440*1080 Resolution |
Exit Pupil Diameter | 6mm |
Exit Pupil distance | 65mm |
Eyepieces Magnification | 11.2X |
Basic Magnification | X3.25 | X4.65 | X1.91 | X2.72 |
Diopter | Adjustable，-5D~+5D |
Thermal imaging Operation | Brightness/Contrast | Adjustable |
NUC | Auto/Manual |
Polarity | Black/White/Green/Iron/Red Hot |
E-Zoom | X1.0~8.0 |
Cross hail | Support .Up to 10 kinds |
Hot Spot track | Support |
PIP | Support |
Bad Pixel correction | Support |
WIFI | Support . AP/WLAN |
Memory | Capacity | 32G |
Audio Record | Support |
Impact Video Recording | Support |
Recording Type | Photo/Video |
Power Supply | Battery Type | Two Power supply Support , Built in type plus external Battery (CR123*1) |
Power working Status | Support |
Working Time | ≥15 Hours |
Environment | Shock Resistance | 800g/ms |
Vibration Resistance | 2g，GB/T2423.10（IEC60068-2-6） |
EMC | CE Complied |
Humidity | 0~95% |
Working Temperature | -30℃~+55℃ (-22 °F to 131°F) |
Physical Characteristics | Housing Color | Black |
Mounting Method | 30mm Tube， Universal Mounting ring |
Encapsulation | IP67 |
Dimension | 351×84×76.2mm（W/ Eyeshade） | 368.2×84×77.2mm（ W/ Eyeshade) | 351×84×76.2mm（ W/ Eyeshade ) | 368.2×84×77.2mm（ W/ Eyeshade ） |
Weight | ≤950g | ≤1100g | ≤950g | ≤1100g |
Interface | Power Supply | Type-C interface (Charging ,Data Transmission, External Video output ) |
Detection distance | People （1.8×0.5）m | 1600m | 2300m | 1600m | 2300m |
Car（2.3×2.3）m | 2200m | 3200m | 2200m | 3200m |
Recognition Distance | People （1.8×0.5）m | 800m | 1150m | 800m | 1150m |
Car（2.3×2.3）m | 1100m | 1600m | 1100m | 1600m |
