Items | RS325-384 | RS335-384 | RS350-384 |
Sensor | Type | Uncooled Vox FPA Micro bolometer |
Pixel Array | 384×288 |
Pixel Pitch | 12μm |
NETD | ≤40mk |
Image | Focal Length | 25mm | 35mm | 50mm |
FOV(±5%) | 10.6°*7.9° | 7.5°*5.7° | 5.3°*4.0° |
Frame Rate | 50HZ |
Focus Method | Manual |
Display | Display | Color Lcos 1280*960 resolution |
Exit Pupil Distance | 55mm |
Eyepieces Magnification | 10X |
Basic Magnification | x2.3 | x3.25 | x4.65 |
Diopter | Adjustable |
Thermal imaging Operation | Brightness/Contrast | Adjustable |
Polarity | White/Black hot |
E-Zoom | x2，x3，x4 |
Cross Hail | Support |
WIFI | Support |
Memory | Memory | 32G |
Recording Type | Video/photo Recording |
Power Supply | Battery Type | Built-In Rechargeable Lithium Battery |
Running time | ＞5 Hours |
Environment | Shock Resistance | 800G |
Vibration Resistance | 2g，GB/T2423.10（IEC60068-2-6） |
EMC | Complied with CE |
Humidity | 0~95% |
Working Temperature | -20℃~+50℃ |
Storage Temperature | -40℃~+70℃ |
Physical Characteristics | Housing Color | Black |
Mounting | Standard 30 mm Tube Ring for mount rail |
Encapsulation | IPX6 |
Dimension | 330×76×74mm（W/ eye shade） |
Weight | ＜900g |
Interface | USB Type-C | Type-C （Charging、data transfer） |
Detection Distance | People（1.8×0.5）m | 1000m | 1400m | 1900m |
Car（2.3×2.3）m | 1600m | 2200m | 3200m |
Recognition Distance | People（1.8×0.5）m | 500m | 700m | 1000m |
Car（2.3×2.3）m | 800m | 1100m | 1600m |
